SKU: STUR35-GPW
Hardware System CPU ARM Cortex-A7,528 MHz Memory 128 MB DDR3 RAM and 128MB Flash Extendable Storage 1 × Micro SD Cellular Interface Antenna Connector 2 × 50 O SMA Connectors (Center PIN: SMA Female) SIM Slots 2(Mini SIM-2FF) Ethernet Interface Numbers 5 × 10/100 Mbps Property 1 × WAN + 4 × LAN Mode Full or half duplex (Auto-Sensing) PoE 4 × 802.3 af/at PoE PSE on LAN Ports (Optional) Wi-Fi Interface (Optional) Antenna Connector 1 × 50 O SMA Connector (Center PIN: RP-SMA Female) Standards IEEE 802.11 b/g/n,2.4GHz Tx Power 802.11b: 16 dBm +/-1.5 dBm (11 Mbps) 802.11g: 14 dBm +/-1.5 dBm (54 Mbps) 802.11n: 13 dBm +/-1.5 dBm (65 Mbps, HT20/40 MCS7) Modes AP or Client mode Security WPA/WPA2 authentication, WEP/TKIP/AES encryption GPS (Optional) Antenna Connector 1 × 50 O SMA Connector (Center PIN: SMA Female) Protocol NMEA0183, PMTK Serial Interface Numbers 1 × RS232 + 1 × RS485 (2 × RS485 Optional) Connector 3.5mm Terminal Block Baud Rate 300bps to 230400bps DI/DO Numbers 1 × DI (dry contact) + 1 × DO (wet contact), Galvanic Isolation Connector 3.5mm Terminal Block Maximum V/A 0.3A@30VDC (DO) Others Reset Button 1 × RESET LED Indicators 1 × POWER, 1 × SYSTEM, 1 × SIM, 1 × Wi-Fi, 1 × VPN, 3 × Signal strength Built-in Watchdog, Timer Software Network Protocols IPV4/IPV6, PPP, PPPOE, SNMP v1/v2c/v3.,TCP, UDP, DHCP,RIPv1/v2,OSPF, DDNS, VRRP, HTTP, HTTPS, DNS, ARP, QOS, SNTP, Telnet, VLAN,SSH,TR069, MQTT, MQTTS, etc. VPN DMVPN, IPsec, OpenVPN, PPTP, L2TP, GRE,WireGuard, MilesightVPN Security Access Control, DMZ, Port Mapping, MAC Binding, SPI Firewalls, DoS&DDoS Protection, Filtering(IP&Domain), IP Passthrough Management Web, CLI, SMS, On-demand dial up, SNMP v1/v2/v3, DeviceHub AAA Radius, Tacacs+, LDAP, Local Authentication Multilevel Authority Multiple Levels of User Authority Reliability VRRP, WAN Failover, Dual SIM Backup Serial Port Transparent(TCP Client/Server, UDP), Modbus Master/Slave, Modbus Gateway (Modbus RTU to Modbus TCP) Power Supply and Consumption Power Connector 2-pin 5.08 mm Terminal Block Input Voltage 9-48 VDC, with Surge-Protection and Reverse Polarity Protection (48V is needed for PoE output) Power Consumption Typical 3.9 W, Max 4.6 W (In Non-PoE mode) Physical Characteristics Ingress Protection IP30 Housing & Weight Metal, 485 g Dimension 135 x 103 x 45 mm (5.31 x 4.06 x 1.77 in) Installation Desktop, Wall or DIN Rail Mounting Environmental Operating Temperature -40°C to +70°C (-40? to +158?) Reduced Cellular Performance Above 60°C Storage Temperature -40°C to +85°C (-40? to +185?) Ethernet Isolation 1.5 kV RMS Relative Humidity 0% to 95% (non-condensing) at 25°C/77? Approvals Regulatory CE, FCC, RCM Environmental RoHS EMC EN 55032, EN 55035 EMS IEC 61000-4-2 Level 3 IEC 61000-4-3 Level 2 IEC 61000-4-4 Level 3 IEC 61000-4-5 Level 3 IEC 61000-4-6 Level 3 IEC 61000-4-8 Level 4 IEC 61000-4-11 Level 3 Radio Frequency EN 301 489-1/17/19/52, EN 301 511, EN 301 908-1/2/13, EN 303 413, EN300 328 Safety EN62368-1
